Recall 22V-070: Transmission Mechatronics – 2022 BMW 3 Series, 5 Series, X3, & X4

SEOCONTENT-START

2/15/22, 8:48 PM 24 01 22_RECALL 22V-070: REPLACE TRANSMISSION MECHATRONICS 1/4 SIB 24 01 22 RECALL 22V-070: REPLACE TRANSMISSION MECHATRONICS 2022-02-15 This Service Information Bulletin (Revision 1) replaces SI B24 01 22 dated January 2022. What’s New (Specific text highlighted): Necessary information provided to complete this Recall MODEL E-Series Model Description Production Date G01 X3 Sports Activity Vehicle December 3, 2021 G02 X4 Sports Activity Coupe December 14, 2021 G20 3 Series Sedan August 13, 2021 G30 5 Series Sedan November 3, 2021 AFFECTED VEHICLES Please perform the procedure outlined in this Service Information on all affected vehicles before customer delivery. In the event the customer has already taken delivery of the vehicle, please perform the procedure the next time the vehicle is in the shop. SITUATION BMW AG is conducting a Voluntary Safety Recall (effective February 3, 2022) on four Model Year 2022 BMW vehicles that were produced between August 3, 2021, and December 14, 2021. There is possibility that the fastening of the mechatronics of the automatic transmission was not carried out correctly. To fix this issue, the transmission mechatronics will need to be replaced. The Recall Notice has been attached for further information. CORRECTION Replace the automatic transmission mechatronics. PROCEDURE Replace the automatic transmission mechatronics according to repair instructions 24 34 613 Replace mechatronics (after vehicle diagnosis) (without programming/encoding, see 61 00 …) PARTS INFORMATION Obtain and confirm the part number below for your specific vehicle by entering the chassis number in either ETK or AIR which takes into account the specific equipment and/or options. Part Number Description Quantity 24 34 5A131E0 RP mechatronics repair kit (GA8HP76Z) 1 24 34 5A131E4 RP mechatronics repair kit (GA8HP51Z) 1 24 34 5A131E6 RP mechatronics repair kit (GA8HP51Z) 1 24 34 8098297 RP mechatronics repair kit 1 83 22 2289720 Automatic transmission fluid 3+ (1 liter) 6 liters in sublet CLAIM INFORMATION During this workshop visit, the affected vehicle may also show one or more programming and encoding Technical Campaign repairs open, the programming and encoding procedure may only be invoiced one time. Copyright ©2022 BMW of North America, Inc. 2/15/22, 8:48 PM 24 01 22_RECALL 22V-070: REPLACE TRANSMISSION MECHATRONICS 2/4 Select one of these open Technical Campaigns to perform and submit for updating the vehicle to the required I-level or higher after the replacement of the mechatronics control module. Please be sure to also perform any additional before and/or after work (including attaching labels) as required by the open campaigns on the vehicle. Close any other open programming and encoding Campaign repairs as outlined in the corresponding Service Information Bulletin. As determined by the above, reimbursement for this Recall will be via normal claim entry utilizing the work package information below that applies. Defect Code: 0024660100 G0x G20 G30 Replacing automatic transmission mechatronics Completion before the first vehicle delivery to a customer or the vehicle is already in the workshop Work Pkg Labor Operation Description (Plus work) Labor Allowance # 1 00 72 522 Replacing the automatic transmission, mechatronics, programming and encoding the vehicle control units (includes providing support voltage for the vehicle electrical system and performing a vehicle test) 29 FRU (X3, X4); 31 FRU (330i, 530i) Or: # 2 00 72 523 Replacing the automatic transmission, mechatronics, programming and encoding the vehicle control units was performed in conjunction with another campaign/repair during this workshop visit 21 FRU (X3, X4); 22 FRU (330i); 23 FRU (530i) Or: The vehicle arrives at your center and this Recall shows open (No other Main work will be performed or claimed during this workshop visit) Work Pkg Labor Operation Description (Main work) Labor Allowance # 3 00 72 017 Replacing the automatic transmission, mechatronics, programming and encoding the vehicle control units (includes providing support voltage for the vehicle electrical system and performing a vehicle test) 31 FRU (X3, X4); 32 FRU (330i); 33 FRU (530i) Or: # 4 00 72 018 Replacing the automatic transmission, mechatronics, programming and encoding the vehicle control units was performed in conjunction with another campaign/repair during to this workshop visit 23 FRU (X3, X4); 24 FRU (330i); 25 FRU (530i) Only one of the flat rate labor operation codes listed above can be used for claim submission/reimbursement purposes. Also, only one Main work flat rate labor operation code can be claimed per workshop visit. Claim Repair Comments Copyright ©2022 BMW of North America, Inc. 2/15/22, 8:48 PM 24 01 22_RECALL 22V-070: REPLACE TRANSMISSION MECHATRONICS 3/4 Only reference the SIB number and the work package (Pkg) number performed in the RO technician notes and the claim comments (For example: B24 01 22 WP 1), unless otherwise required by State law. And: Sublet – Bulk Materials (RO and Claim Comments Required) Sublet Code 4 Up to $350.00 Reimbursement for the repair-related bulk materials (Do not use the BMW part numbers for claim submission) Sublet reimbursement calculation for claiming the applicable repair-related bulk material (BMW part numbers) is at the dealer net price amount for the quantity used plus your center’s handling. Enter this material cost in sublet and itemize the amount on the repair order and in claim comment section. Programming and Encoding – Vehicle Control Units (RO and Claim Comments Required) This procedure automatically reprograms and encodes any vehicle control modules that do not have the latest software I-level. If one or more control modules fail during the reprogramming procedure, claim the required consequential repair work procedures to address this issue (including performing the IRAP Control Unit Recovery first as required, refer to the SIB in AIR) under the Defect Code in this bulletin with the labor operations in AIR that apply. Please explain the additional work procedures that were performed (The why and the what) on the repair order and in the claim comments. For covered repairs that address control module failures that occurred prior to performing this reprogramming procedure, claim this work with the Defect Code and labor operations (including diagnosis) in AIR that apply. Based on which one applies to your center, please refer to SI B01 01 20 or B01 07 20 for the applicable procedure for documenting, claiming, and explaining, on the RO and in the claim comments, your diagnosis work time (WT), job/repair work time (WT), and the vehicle repairs your center performed, unless otherwise required by State law. And, when applicable: Alternative Mobility Solution (AMS) for Vehicle Owners (RO and Claim Comments Required) This Recall repair qualifies for Alternative Mobility Solution (AMS) expense reimbursement, claim this item under the Defect Code noted above as follows: Sublet Code 2 – Itemize the AMS sublet amount on the repair order and in the claim comment section. Please refer to SI B01 29 16 for additional information. Reimbursement of Prior Customer-Pay Repairs (TREAD Act) Based on the issue and the age of the Affected Vehicles being addressed by this Safety Recall Campaign, a reimbursement request for a qualifying prior customer-pay repair is not likely. However, if you do receive a reimbursement request from a customer for a prior repair that may qualify, please contact the Warranty department (include a legible copy of the invoice) through IDS by selecting Copyright ©2022 BMW of North America, Inc. 2/15/22, 8:48 PM 24 01 22_RECALL 22V-070: REPLACE TRANSMISSION MECHATRONICS 4/4 Coverage, Policy, Coding Questions and Mileage Corrections. The Warranty department will review and respond to your inquiry accordingly. QUESTIONS REGARDING THIS BULLETIN Technical inquiries Submit feedback at the top of this bulletin Warranty inquiries Please contact the Warranty department by either using the Live Chat that’s available in the Warranty Documentation Portal or through IDS by selecting Coverage, Policy, Coding Questions and Mileage Corrections Parts inquiries Submit an IDS ticket to the Parts Department Supporting Materials picture_as_pdf Attachment B240122 Recall Notice.pdf Copyright ©2022 BMW of North America, Inc. Attachment to B24 01 22 February 2022 SAFETY RECALL NOTICE To: All Center Operators, Sales Managers, Service Manager, Parts Manager and Warranty Processor RE: Recall 22V-070: Transmission Mechatronics – B24 01 22 BMW AG is conducting a Voluntary Safety Recall (effective February 3, 2022) on four Model Year 2022 BMW vehicles that were produced between August 3, 2021 and December 14, 2021. Please be reminded that it is a violation of federal law (The Safety Act) for you to sell, lease or deliver any new motor vehicle covered by this notification until the recall repair has been performed. This means that centers may not legally deliver new motor vehicles to consumers until they are fixed or use/sell replacement equipment/parts subject to this recall. Note also that substantial civil penalties apply to violations of the Safety Act. Also, you should not sell, lease or deliver any Certified Pre-Owned or used vehicles subject to a safety recall until the repair is completed. Please follow any special instructions that we provide to you for the return or disposition of recall parts. We appreciate all your assistance with this Recall.

**************************************************************************************************************

From: Broadcast Messaging System To: DL-BMS_Message_Monitors Subject: BMW Recall 22V-xxx: Transmission Mechatronics Date: Thursday, February 3, 2022 12:46:50 PM Publish Date: From: Expiration Date: February 3, 2022 Technical Service February 17, 2022 DCSnet Message Urgent Subject: BMW Recall 22V-xxx: Transmission Mechatronics BMW AG is conducting a Voluntary Safety Recall (effective February 3, 2022) on four Model Year 2022 BMW vehicles that were produced between August 3, 2021 and December 14, 2021. There is possibility that the screwing of the mechatronics of the automatic transmission was not carried out correctly. To fix this issue, the transmission mechatronics will need to be replaced. The Recall Notice has been attached for further information. The bulletin will be updated when additional information becomes available. Sincerely, Technical Service Attachments: B240122 Recall Notice[1643908133411].pdf B240122[1643908133411].pdf B240122 Recall Notice[1643908133411].pdf B240122[1643908133411].pdf Recipients: BMW Passenger Cars, 50923, BMW of Plano/MINI of Plano, All Departments, All Personnel BMW Passenger Cars, 31643, Long Beach BMW, All Departments, All Personnel BMW Passenger Cars, 30462, BMW of Freehold, All Departments, All Personnel BMW SAV (Light Trucks) 30462 BMW of Freehold All Departments All Personnel 2/7/22, 6:09 PM 24 01 22_RECALL 22V-XXX: TRANSMISSION MECHATRONICS 1/1 SIB 24 01 22 RECALL 22V-XXX: TRANSMISSION MECHATRONICS 2022-02-03 MODEL E-Series Model Description Production Date G01 X3 Sports Activity Vehicle December 3, 2021 G02 X4 Sports Activity Coupe December 14, 2021 G20 3 Series Sedan August 13, 2021 G30 5 Series Sedan November 3, 2021 AFFECTED VEHICLES Vehicles which require this Recall Campaign to be completed will show it as “Open” when checked either in AIR, the “Service Menu” of DCSnet (Dealer Communication System), ISPA Next or Warranty Vehicle Inquiry. SITUATION BMW AG is conducting a Voluntary Safety Recall (effective February 3, 2022) on four Model Year 2022 BMW vehicles that were produced between August 3, 2021 and December 14, 2021. There is possibility that the screwing of the mechatronics of the automatic transmission was not carried out correctly. To fix this issue, the transmission mechatronics will need to be replaced. The Recall Notice has been attached for further information. The bulletin will be updated when additional information becomes available. Supporting Materials picture_as_pdf B240122 Recall Notice.pdf Copyright ©2022 BMW of North America, Inc. Attachment to B24 01 22 February 2022 SAFETY RECALL NOTICE To: All Center Operators, Sales Managers, Service Manager, Parts Manager and Warranty Processor RE: Recall 22V-xxx: Transmission Mechatronics – B24 01 22 BMW AG is conducting a Voluntary Safety Recall (effective February 3, 2022) on four Model Year 2022 BMW vehicles that were produced between August 3, 2021 and December 14, 2021. Please be reminded that it is a violation of federal law (The Safety Act) for you to sell, lease or deliver any new motor vehicle covered by this notification until the recall repair has been performed. This means that centers may not legally deliver new motor vehicles to consumers until they are fixed or use/sell replacement equipment/parts subject to this recall. Note also that substantial civil penalties apply to violations of the Safety Act. Also, you should not sell, lease or deliver any Certified Pre-Owned or used vehicles subject to a safety recall until the repair is completed. Please follow any special instructions that we provide to you for the return or disposition of recall parts. We appreciate all your assistance with this Recall.

**************************************************************************************************************

OMB Control No.: 2127-0004 Part 573 Safety Recall Report 22V-070 The information contained in this report was submitted pursuant to 49 CFR §573 Manufacturer Name : BMW of North America, LLC Submission Date : FEB 09, 2022 NHTSA Recall No. : 22V-070 Manufacturer Recall No. : NR Manufacturer Information : Manufacturer Name : BMW of North America, LLC Address : P.O. Box 1227 Westwood NJ 07675-1227 Company phone : 18005257417 Population : Number of potentially involved : 4 Estimated percentage with defect : 100 % Vehicle Information : Vehicle 1 : 2022-2022 BMW 330i Vehicle Type : LIGHT VEHICLES Body Style : 4-DOOR Power Train : GAS Descriptive Information : Approximately 1 vehicle has been manufactured with a transmission mechatronics unit that may not have been assembled by the supplier according to specifications. Basis for recall population determination: Supplier production records and vehicle assembly information were reviewed to determine the production dates of potentially affected vehicles. Recall component difference to non-recall component: The transmission mechatronics unit may not have assembled by the supplier according to specifications. Production Dates : AUG 13, 2021 – AUG 13, 2021 VIN Range 1 : Begin : NR End : NR Not sequential Part 573 Safety Recall Report 22V-070 Page 2 The information contained in this report was submitted pursuant to 49 CFR §573 Vehicle 2 : 2022-2022 BMW 530i Vehicle Type : LIGHT VEHICLES Body Style : 4-DOOR Power Train : GAS Descriptive Information : Approximately 1 vehicle has been manufactured with a transmission mechatronics unit that may not have been assembled by the supplier according to specifications. Basis for recall population determination: Supplier production records and vehicle assembly information were reviewed to determine the production dates of potentially affected vehicles. Recall component difference to non-recall component: The transmission mechatronics unit may not have assembled by the supplier according to specifications. Production Dates : NOV 03, 2021 – NOV 03, 2021 VIN Range 1 : Begin : NR End : NR Not sequential Vehicle 3 : 2022-2022 BMW X3 xDrive30i Vehicle Type : LIGHT VEHICLES Body Style : SUV Power Train : GAS Descriptive Information : Approximately 1 vehicle has been manufactured with a transmission mechatronics unit that may not have been assembled by the supplier according to specifications. Basis for recall population determination: Supplier production records and vehicle assembly information were reviewed to determine the production dates of potentially affected vehicles. Recall component difference to non-recall component: The transmission mechatronics unit may not have assembled by the supplier according to specifications. Production Dates : DEC 03, 2021 – DEC 03, 2021 VIN Range 1 : Begin : NR End : NR Not sequential Part 573 Safety Recall Report 22V-070 Page 3 The information contained in this report was submitted pursuant to 49 CFR §573 Vehicle 4 : 2022-2022 BMW X4 xDrive30i Vehicle Type : LIGHT VEHICLES Body Style : SUV Power Train : GAS Descriptive Information : Approximately 1 vehicle has been manufactured with a transmission mechatronics unit that may not have been assembled by the supplier according to specifications. Basis for recall population determination: Supplier production records and vehicle assembly information were reviewed to determine the production dates of potentially affected vehicles. Recall component difference to non-recall component: The transmission mechatronics unit may not have assembled by the supplier according to specifications. Production Dates : DEC 14, 2021 – DEC 14, 2021 VIN Range 1 : Begin : NR End : NR Not sequential Description of Defect : Description of the Defect : This safety recall involves the transmission. During supplier production, the transmission mechatronics unit may not have been assembled according to specifications. One or more bolts may not have been attached according to specifications which could cause an internal leak. In rare cases, this could result in a rollaway condition. FMVSS 1 : NR FMVSS 2 : NR Description of the Safety Risk : A rollaway condition could increase the risk of a crash and/or injury. Description of the Cause : NR Identification of Any Warning that can Occur : NR Involved Components : Component Name 1 : Transmission Mechatronics Unit Component Description : Transmission Mechatronics Unit Component Part Number : 5A131E6 Part 573 Safety Recall Report 22V-070 Page 4 The information contained in this report was submitted pursuant to 49 CFR §573 Supplier Identification : Component Manufacturer Name : ZF Friedrichshafen AG Address : Suedring Saarbruecken Foreign States 66117 Country : Germany Chronology : On January 13, 2022, BMW was notified by the transmission supplier of a possibility that certain transmissions may not have been assembled according to specifications. The supplier had recently noticed that on one of the mechatronics units, all of the required bolts necessary to assemble the unit were not present. An engineering and supplier review was initiated. During that review, supplier process records were analyzed. It was found that, due to a supplier control system error, mechatronic units which may have been misassembled were nevertheless moved along in the production sequence. A review of the supplier production database determined the specific units which may have been misassembled and, moreover, the specific bolts which may not have been included. In addition, due to parts traceability, specific potentially affected vehicles were able to be identified. Vehicle assembly information and supplier production records were reviewed to determine the number and production dates of potentially affected vehicles. On February 2, 2022, BMW decided to conduct a voluntary recall. BMW has not received any reports, nor is BMW otherwise aware, of any accidents or injuries that may be related to this issue. Description of Remedy : Description of Remedy Program : The transmission mechatronics unit will be replaced. Owners are planned to be notified by phone and, if necessary, will be notified by First Class mail and instructed to take their vehicle to an authorized BMW dealer to have the remedy performed for free. If this condition was noticed on a potentially affected vehicle prior to this recall, the remedy would be covered by the BMW New Vehicle Limited Warranty program. Therefore, reimbursement for a pre-notification remedy re Part 573.13 and Part 577.11 is not necessary. Part 573 Safety Recall Report 22V-070 Page 5 The information contained in this report was submitted pursuant to 49 CFR §573 How Remedy Component Differs from Recalled Component : Recalled Component: Transmission Mechatronics Unit – part number – 5A131E6 Identify How/When Recall Condition was Corrected in Production : NR Recall Schedule : Description of Recall Schedule : Notification to dealers is planned to begin and end on February 9, 2022. Notification to owners is planned to begin and end on April 4, 2022. Planned Dealer Notification Date : FEB 09, 2022 – FEB 09, 2022 Planned Owner Notification Date : APR 04, 2022 – APR 04, 2022 * NR – Not Reported

**************************************************************************************************************

OMB Control No.: 2127-0004 Part 573 Safety Recall Report 22V-070 The information contained in this report was submitted pursuant to 49 CFR §573 Manufacturer Name : BMW of North America, LLC Submission Date : APR 04, 2022 NHTSA Recall No. : 22V-070 Manufacturer Recall No. : NR Manufacturer Information : Manufacturer Name : BMW of North America, LLC Address : P.O. Box 1227 Westwood NJ 07675-1227 Company phone : 18005257417 Population : Number of potentially involved : 4 Estimated percentage with defect : 100 % Vehicle Information : Vehicle 1 : 2022-2022 BMW 330i Vehicle Type : LIGHT VEHICLES Body Style : 4-DOOR Power Train : GAS Descriptive Information : Approximately 1 vehicle has been manufactured with a transmission mechatronics unit that may not have been assembled by the supplier according to specifications. Basis for recall population determination: Supplier production records and vehicle assembly information were reviewed to determine the production dates of potentially affected vehicles. Recall component difference to non-recall component: The transmission mechatronics unit may not have assembled by the supplier according to specifications. Production Dates : AUG 13, 2021 – AUG 13, 2021 VIN Range 1 : Begin : NR End : NR Not sequential Part 573 Safety Recall Report 22V-070 Page 2 The information contained in this report was submitted pursuant to 49 CFR §573 Vehicle 2 : 2022-2022 BMW 530i Vehicle Type : LIGHT VEHICLES Body Style : 4-DOOR Power Train : GAS Descriptive Information : Approximately 1 vehicle has been manufactured with a transmission mechatronics unit that may not have been assembled by the supplier according to specifications. Basis for recall population determination: Supplier production records and vehicle assembly information were reviewed to determine the production dates of potentially affected vehicles. Recall component difference to non-recall component: The transmission mechatronics unit may not have assembled by the supplier according to specifications. Production Dates : NOV 03, 2021 – NOV 03, 2021 VIN Range 1 : Begin : NR End : NR Not sequential Vehicle 3 : 2022-2022 BMW X3 xDrive30i Vehicle Type : LIGHT VEHICLES Body Style : SUV Power Train : GAS Descriptive Information : Approximately 1 vehicle has been manufactured with a transmission mechatronics unit that may not have been assembled by the supplier according to specifications. Basis for recall population determination: Supplier production records and vehicle assembly information were reviewed to determine the production dates of potentially affected vehicles. Recall component difference to non-recall component: The transmission mechatronics unit may not have assembled by the supplier according to specifications. Production Dates : DEC 03, 2021 – DEC 03, 2021 VIN Range 1 : Begin : NR End : NR Not sequential Part 573 Safety Recall Report 22V-070 Page 3 The information contained in this report was submitted pursuant to 49 CFR §573 Vehicle 4 : 2022-2022 BMW X4 xDrive30i Vehicle Type : LIGHT VEHICLES Body Style : SUV Power Train : GAS Descriptive Information : Approximately 1 vehicle has been manufactured with a transmission mechatronics unit that may not have been assembled by the supplier according to specifications. Basis for recall population determination: Supplier production records and vehicle assembly information were reviewed to determine the production dates of potentially affected vehicles. Recall component difference to non-recall component: The transmission mechatronics unit may not have assembled by the supplier according to specifications. Production Dates : DEC 14, 2021 – DEC 14, 2021 VIN Range 1 : Begin : NR End : NR Not sequential Description of Defect : Description of the Defect : This safety recall involves the transmission. During supplier production, the transmission mechatronics unit may not have been assembled according to specifications. One or more bolts may not have been attached according to specifications which could cause an internal leak. In rare cases, this could result in a rollaway condition. FMVSS 1 : NR FMVSS 2 : NR Description of the Safety Risk : A rollaway condition could increase the risk of a crash and/or injury. Description of the Cause : NR Identification of Any Warning that can Occur : NR Involved Components : Component Name 1 : Transmission Mechatronics Unit Component Description : Transmission Mechatronics Unit Component Part Number : 5A131E6 Part 573 Safety Recall Report 22V-070 Page 4 The information contained in this report was submitted pursuant to 49 CFR §573 Supplier Identification : Component Manufacturer Name : ZF Friedrichshafen AG Address : Suedring Saarbruecken Foreign States 66117 Country : Germany Chronology : On January 13, 2022, BMW was notified by the transmission supplier of a possibility that certain transmissions may not have been assembled according to specifications. The supplier had recently noticed that on one of the mechatronics units, all of the required bolts necessary to assemble the unit were not present. An engineering and supplier review was initiated. During that review, supplier process records were analyzed. It was found that, due to a supplier control system error, mechatronic units which may have been misassembled were nevertheless moved along in the production sequence. A review of the supplier production database determined the specific units which may have been misassembled and, moreover, the specific bolts which may not have been included. In addition, due to parts traceability, specific potentially affected vehicles were able to be identified. Vehicle assembly information and supplier production records were reviewed to determine the number and production dates of potentially affected vehicles. On February 2, 2022, BMW decided to conduct a voluntary recall. BMW has not received any reports, nor is BMW otherwise aware, of any accidents or injuries that may be related to this issue. Description of Remedy : Description of Remedy Program : The transmission mechatronics unit will be replaced. Owners are planned to be notified by phone and, if necessary, will be notified by First Class mail and instructed to take their vehicle to an authorized BMW dealer to have the remedy performed for free. If this condition was noticed on a potentially affected vehicle prior to this recall, the remedy would be covered by the BMW New Vehicle Limited Warranty program. Therefore, reimbursement for a pre-notification remedy re Part 573.13 and Part 577.11 is not necessary. Part 573 Safety Recall Report 22V-070 Page 5 The information contained in this report was submitted pursuant to 49 CFR §573 How Remedy Component Differs from Recalled Component : Recalled Component: Transmission Mechatronics Unit – part number – 5A131E6 Identify How/When Recall Condition was Corrected in Production : NR Recall Schedule : Description of Recall Schedule : Notification to dealers is planned to begin and end on February 9, 2022. Notification to owners is planned to begin and end on April 4, 2022. As of April 4th, all 4 vehicles (owners) have been contacted by phone, and all 4 vehicles have been repaired. Therefore, an ONL is not necessary. Planned Dealer Notification Date : FEB 09, 2022 – FEB 09, 2022 Planned Owner Notification Date : APR 04, 2022 – APR 04, 2022 * NR – Not Reported

**************************************************************************************************************
