NHTSA ID Number: 10161589
Manufacturer Communication Number: MC5200119
Summary
As a part of the ongoing quality analysis, BMW
Motorrad has found that the seat does not fulfill the requirements with respect to waterproofness, whereby water can penetrate into the helmet holder.
1 Affected Product
Vehicle
| MAKE | MODEL | YEAR |
| BMW | C 400 X | 2019 |
Details
As a part of the ongoing quality analysis, BMW Motorrad has found that the seat does not fulfill the requirements with respect to waterproofness, whereby water can penetrate into the helmet holder.
Identification of the components
The seats are indistinguishable externally. Mark the old seat before removal.
Vehicles affected
In order to determine if a specific vehicle is affected by this Technical Campaign, it will be necessary to verify all VIN’s through AIR (Aftersales Information Research). Based on the response of the system, either proceed with the repair or take no further action. Please note, VIN’s in DCS Vehicle History Check may not appear until 24-72 hours after the release of this bulletin, therefore AIR is the recommended method for determining open campaigns.
Production Solution
As of 10/24/2018 vehicles have been fitted with redesigned seats.
Service Solution
For affected vehicles prior to delivery or during the next workshop visit, the seat is to be renewed as per repair instructions 52 53 059 Renewing complete dualseat in AIR (Aftersales Information Research).
Warranty processing
Covered by the normal terms of the BMW New Motorcycle Limited Warranty.
SEOCONTENT-START
© 2019, BMW of North America, LLC.
The contents of this document are confidential and should not be shared with third parties for distribution.
All prices subject to change without notice. 05/2019
Replacing Seat
C 400 X (K09, 0C19)
Service Information No. SI 52 001 19
Service Information No. SI 52 001 19
C 400 X (K09, 0CC19) Replacing Seat
© 2019, BMW of North America, LLC. Page 2
The contents of this document are confidential and should not be shared with third parties for distribution.
All prices subject to change without notice. 05/2019
Details
As a part of the ongoing quality analysis, BMW Motorrad has found that the seat does not fulfill the requirements with respect
to waterproofness, whereby water can penetrate into the helmet holder.
Figure 1: Seat C 400 X
Identification of the components
The seats are indistinguishable externally. Mark the old seat before removal.
Vehicles affected
In order to determine if a specific vehicle is affected by this Technical Campaign, it will be necessary to verify all VIN’s
through AIR (Aftersales Information Research). Based on the response of the system, either proceed with the repair or take
no further action. Please note, VIN’s in DCS Vehicle History Check may not appear until 24-72 hours after the release of this
bulletin, therefore AIR is the recommended method for determining open campaigns.
Production Solution
As of 10/24/2018 vehicles have been fitted with redesigned seats.
Service Solution
For affected vehicles prior to delivery or during the next workshop visit, the seat is to be renewed as per repair instructions
52 53 059 Renewing complete dualseat in AIR (Aftersales Information Research).
Warranty processing
Covered by the normal terms of the BMW New Motorcycle Limited Warranty.
Defect code
00 52 01 00 00 Replacing seat
FRU number
*52 53 059 Renewing complete dualseat, 5 FRU’s
+52 53 574 Renewing complete dualseat, 4 FRU’s
*Main Work: These main labor operations include all repair procedures to complete the task with allowance for necessary
ancillary tasks (e.g. visual inspection, lubrication, cleaning parts, use of thread-locking compound etc.) and administrative
tasks. Only one main labor operation can be claimed per repair visit. All other labor operations for any other line(s) must be
claimed using plus code labor operations. Please refer to the Warranty Policy and Procedures Manual regarding add-ons,
proper support, documentation, claims submission and archiving requirements as applicable.
Part number
07 12 9 908 076 2x Socket-head screw, M6x20
— — – — — Seat (see Electronic Parts Catalogue)
Questions regarding this bulletin?
For technical inquires in relation to this bulletin Please contact the Motorrad Technical Support Group
For warranty inquires in relation to this bulletin. Submit an IDS ticket to the Warranty Department
For parts inquires in relation to this bulletin Submit an IDS ticket to the Motorrad Parts Department
SEOCONTENT-END
Service Information No. SI 52 001 19
05/2019
