March 21, 2024 NHTSA CAMPAIGN NUMBER: 24E029000
Accessory Side Case May Detach from Motorcycle
A side case lid that detaches or the case contents that fall out, can create a road hazard and increase the risk of a crash.
NHTSA Campaign Number: 24E029
Manufacturer BMW of North America, LLC
Components EQUIPMENT
Potential Number of Units Affected 1,600
Summary
BMW of North America, LLC (BMW) is recalling certain BMW motorcycle dealer accessory side cases, designed to fit R1300 GS motorcycles, with part number: 77 41 9 444 361/362. The side case latch hooks may not snap properly into the lock, which can result in the case lid opening, and possibly detaching from the motorcycle.
Remedy
Dealers will repair the locking mechanism and hinges of the side cases, free of charge. Owner notification letters are expected to be mailed May 13, 2024. Owners may contact BMW customer service at 1-800-525-7417.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.
SIB 00 02 24
2024-04-01
INFO – Vario Case/s Compensation
MODEL
Model | Model Description | Model Code |
KA1 | R 1300 GS | 0M23 |
SITUATION
There is currently a recall for the Vario luggage system of the R 1300 GS (BMW Motorrad Original Accessory Top and Side Cases). The R 1300 GS Vario Case Repair Kits are expected to be available by end of May / early June (pending final confirmation).
BMW Motorrad Aftersales understands there are customer inquiries regarding the current recalls on the Vario luggage systems for the R 1300 GS. During this time of restricted parts availability, you can offer customer support on a case-by-case basis and at dealer’s discretion of compensation that provides up to
$ per VIN. The process for this program is described in this bulletin, including how to obtain compensation.
R 1300 GS VARIO CASE RECALL INFORMATION
Vario Top Case – Recall 24E-020:
- Description of defect or noncompliance:
- This safety recall involves the dealer accessory top case. The locking flap of the top case (fastening the top case to the luggage carrier of the motorcycle) may appear to be securely closed by the user. However, in this condition, the key can be removed. If this occurred, the top case would not be securely fastened to the motorcycle.
- Description of safety risk:
- If the top case detached from the motorcycle, it could become a hazard for road users, and increase the risk of a crash.
Vario Side Cases – Recall 24E-029:
- Description of defect or noncompliance:
- This safety recall involves the dealer accessory side cases. The lid of the side case may appear to be securely closed by the user; however, in isolated cases, both latch hooks may not have snapped properly into the lock. If this occurred, the side case would not be securely closed and could open during riding.
- Description of safety risk:
- If the side case lid opened while riding, the contents of the side case could fall out. Also, the hinges and holding strap may not securely hold the lid and could break, causing the lid to become detached from the side case. The case contents and/or the lid could become a hazard for road users and increase the risk of a crash.
PROCEDURE
In principle, there must be an order for one or more parts of the Vario luggage system and a customer complaint.
Recommended Utilization
This compensation should be an active response to a negative customer experience e.g., customer expressly complains about the delayed delivery or repair of the accessories (and this could possibly jeopardize the delivery/retail report of the vehicle as a result).
Compensation can be used towards a future purchase of the Vario Case/s. Alternatively items such as soft bags are primarily suitable substitutes.
PARTS INFORMATION
Recommendations:
Part Number | Description | Image |
71607689674 | Vehicle cover | A |
77455A0E751 | Tank bag Black Collection large | B |
77455A5CE48 | Connection tank bag (needed for tank bags) | n/a |
77455A3C3D7 | Tank bag Urban Collection large | C |
77455A0E752 | Tank bag Black Collection small | D |
77455A3C3D9 | Tank bag Urban Collection small | E |
77455A50328 | Tank bag Adventure Collection large | F |
77455A503A6 | Tank bag Adventure Collection small | G |
77495A0E757 | Rear bag Black Collection large | H |
77495A0E758 | Rear bag Black Collection small | I |
77495A3C3D0 | Rear bag Urban Collection large | J |
77495A3C3E0 | Rear bag Urban Collection small | K |
77495A503B9 | Rear bag Adventure Collection large | L |
77495A50044 | Rucksack Urban Collection | M |
77495A503C1 | Rucksack Adventure Collection | N |
Chronology :
On October 31,2023, during a dealer demonstration ride of a BMW R 1300 GS in a non-US market, a side case lid opened, the hinges and holding strap broke and the lid contacted the roadway. An engineering investigation was initiated, the part was returned for analysis, and the supplier was contacted.
Tests and analyses were planned to focus on the design of the locking mechanism and the hinges to understand the precision of the locking feature, and the mechanical resistance for the latch hooks when pushed for closing.
The supplier reviewed its records and confirmed that all side cases since start of production had been tested in a 100% end-of-line test, which ensured that all cases would be capable of secure latching if operated correctly.
Additional customer complaints were received in non-US markets, in which customers complained that their side case lids had opened and, in most cases, became detached and contacted the roadway. These parts were requested to be returned for analysis. The first field part was received for analysis on December 1, 2023.
Between December 2023 and March 2024, tests and analyses found that improper locking of the latch hooks was facilitated by the geometry of the latch hooks and the position of the hinges. Additional analyses confirmed that for a lid to detach, both latch hooks would need to be improperly secured. The tests indicated that even if only one of two latch hooks (upper left- or right-hand corner of the side case) was properly locked, the lid would not open even under severe riding stress. Therefore, side cases opening during riding had to be improperly latched on both corners.
On March 14, 2024, BMW decided to conduct a voluntary safety recall for the accessory side cases.
Between November 2023 and March 2024, approximately 14 customer complaints were received in non-US markets.
BMW has not received any reports, nor is BMW otherwise aware, of any accidents or injuries that relate to this issue.
1 Affected Product
Equipment
BRAND | PART NO. | PRODUCTION DATES |
BMW | ACC. SIDE CASE R 1300 GS |
7 Associated Documents
Manufacturer Notices(to Dealers,etc)
Defect Notice 573 Report
RCLRPT-24E029-9815.PDF 215.643KB
Remedy Instructions and TSB
RCRIT-24E029-2861.pdf 154.362KB
Recall Acknowledgement
RCAK-24E029-5763.pdf 700.589KB
Recall 573 Report – 24E029
RCLRPT-24E029-4702.PDF 215.781KB
Recall 573 Report – 24E029
RCLRPT-24E029-7801.PDF 215.781KB
Remedy Instructions and TSB – Remedy Instructions re INFO – Vario Case/s Compensation
RCRIT-24E029-6698.pdf 1593.171KB
Latest Recalls Documents
For the Latest and Most recent Recall Information Visit the link below…
https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=24E029&docType=RCL
- 【Perfect Material】-This r1200gs tool box is a combination of stainless steel and high-quality plastic. The perfect combination of the toughness of plastic and the hardness of stainless steel allows the box to withstand strong impact.
- 【Cover with Lock】-The cover can be removed from the box. Easy to remove and put item back. It comes with locks and keys to protect your important items from theft.
- 【4.2-Liter Large Storage】-Approximately 4.2-liter large storage space provides more room for you to storage tool conveniently.
- 【Excellent Waterproof】-With gaskets, these gaskets can make the mounting holes more sealed during installation and prevent water from entering the box.
- 【Fitment】-Fit for: BMW R1200GS R1250GS LC Adventure & F750 F850 (2002 2008 2018 2019) & Any motorcycle with BMW factory side box bracket.(or other same size side box mount)
- - Special -strip with Velcro for secure attachment to the case. - Expandable up to 20 liter maximum capacity.
- - Expands/compacts with perimeter zipper. - Crossed shock cords on top for quickly securing gloves, hat, etc. - Ergonomic zipper pulls.
- - Waterproof, Teflon-coated CORDURA weave material. Strong, abrasion and fade resistant.
- - They are attached to the vario panniers with a belt that completely covers the bag, two stretch velcro and a belt that joins together passing under the saddle with safety.
- - A belt is also used as a shoulder strap for easy transport. - Ergonomic carrying handle. - Lightweight. - Waterproof zippers. Package Contents: 1 * Motorcycle Top Cover Waterproof Bag Only the above package contents, excluding other products.
- FITEMENT: Fits for BMW K1600B 2018 2019.
- DURABILITY: This inner bags are made of tough PVC waterproof thick textile material with strong black stitches,which is durable, waterproof and insulated, ensuring your belongings stay safe and dry.
- EASY CARRYING: Equipped with adjustable wide shoulder strap, you can pull it out and take it anywhere, convenient for your motorcycle travel.
- PERFECT STORAGE: Additional zipper outer pocket and inner mesh compartment for storing small parts, help organize your item better. Light-colored lining for easy spot your item.
- Solid Construction: Sturdy bottom lining and stud bolts are used to keep clean and keep on the ground. Also this liner bags features with waterproof 360 degree zipper to expand the bag for easy packing.
- Heavy-duty 900D nylon construction
- 1680D Nylon bottom for added protection while liner is removed from the case
- Horseshoe-shaped top entry zipper for easy compartment access
- Easy carry handles complete with hook and loop handle wrap
- Adjustable internal dividers allow riders to configure storage as needed
- 【Application】LKV motorcycle tool box compatible with BMW R1200GS R1250GS LC Adventure and F750 F850 (2002 2008 2018 2019), also replacement for any motorcycle with brand factory side box bracket or other same size side box mount.
- 【4.2-Liter Large Storage】R1200GS tool box with approximately 4.2-liter large storage space provides more room for you to store tools conveniently.
- 【Cover with Lock】The cover can be removed from the left side bracket box. Easy to remove and put the item back. It comes with locks and keys to protect your important items from theft.
- 【Good Material】 This R1250GS tool box case is a combination of stainless steel and high-quality plastic. The perfect combination of the toughness of plastic and the hardness of stainless steel allows the box to withstand strong impact.
- 【Excellent Waterproof】The package contains gaskets that can make the mounting holes more sealed during installation and prevent water from entering the box. A 1-year warranty, if you have any questions about the item, please feel free to contact us, we are always here with you.
- FITMENT: Perfectly fits for BMW R1200GS/ R1250GS/ F750GS/ F850GS original aluminum case.
- MATERIAL: Crafted from tough nylon thick textile material, with strong black stitches, ensuring long-lasting durability.
- EASY CARRYING: Equipped with adjustable and wide shoulder straps, easily transporting your luggage during your tour.
- Optimize Space Usage: Includes an inner pocket and an outer zippered pocket, providing well-organized storage for your item, like maps, passports, and other essentials.
- CONVENIENT STORAGE: The bags can be loaded from the top, ensuring convenient access to the contents in the case. And the inner lining is designed in blue color for easily locate your items.
- 42L left side case, 36L right side case. Fits for BMW R1200GS 2012-2018, R1250GS 2018-2022, R1200GS ADV 2012-2018, R1250GS ADV 2018-2022.
- ♦The cases are made of 5A02 aluminum alloy (Thickness 2mm). Rust proof, with high fatigue strength. ♦Lock bodies, mounting brackets, and rivets are 304 stainless steel. ♦Seals, hinges, handles and corner protecters of the case are reinforced nylon.
- Each case has 2 safety locks. One is used to lock the case onto the mounting bracket, and the other is used to protect the items inside the case. The keys to the cases are universal, which is convenient for daily use.
- The carefully designed fixing method can maintain the stability of the cases. It also allows you to install or remove the entire enclosure quickly and easily. The mounting bracket is included in this product.
- ✔Please note that the bracket is specially designed and usually cannot be used for other vehicle models. ✔We will reply within 24 hours of receiving your emails. If you have any questions, please feel free to contact us.
- 45L CAPACITY SUITABLE FOR DAILY RIDE: With a roomy 45-liter capacity, our motorcycle top case accommodates your daily riding essentials, from helmet to riding gloves, personal items like your phone and sunglasses, and water bottles, making it an ideal motorcycle tank bag and tail bag. this motorcycle bag offers ample space for your belongings, making it an ideal motorcycle trunk and luggage option. The measurement for the motorcycle trunk is 16.5x13x13 inches.
- STRONG & LIGHTWEIGHT ALUMINUM: GURBLOFY motorcycle top box made with heavy duty aluminum and it design for long-lasting, lightweight and strong. It's resistant to rust and corrosion, ensuring that the motorcycle luggage case will remain in excellent condition for over years. And it doesn't add significant weight to the motorcycle, allowing riders to maintain balance and control.
- EASY INSTALLATION AND UNIVERSAL BRACKET: Installing our top case is a breeze, with a universal base bracket that's compatible with most motorcycles tailrack. Follow these simple steps: 1. Unlock the lower lock; 2. Slide out the base bracket; 3. Install the base bracket to the tail rack using the included screws; 4. Slide the top into the base bracket and lock it up.
- WATERPROOF AND DUSTPROOF: With its silicone-sealed construction, this motorcycle helmet bag remains tightly sealed, preventing water and dust from entering, designed to be completely waterproof and dustproof. The silicone seal inside ensures your gear remains protected during your adventures, making it an excellent choice as a motorcycle tail box or motorcycle top box!
- CONSUMER EXPERIENCE IS OUR PRIORITY: All products from GURBLOFY come with a 12-month warranty, and we take pride in offering premium customer service to every one of our customers. Please don't hesitate to reach out if you have any questions or need assistance. We're here to help.
- Made of high quality material, durable and practical to use
- Three low profile synthetic rubber pads are only 0.125 inches thick and precision cut for a perfect fit.
- These handy Pannier Covers create a convenient non-slip platform atop your aluminum hard luggage so you can put your phone, keys or other items without worrying about causing scratches or losing things as they slide off.
- The releasable self-adhesive backing makes installation a snap. Add protection, improve versatility and keep your top case looking like new with this Pannier Cover Set!
- For BMW R1200GS 2013-2018 For BMW R1200GS LC Adventure 2014-2019
- For BMW R 1200 GS (-2007) For BMW R 1200 GS (2008 - 2009) For BMW R 1200 GS (2010 - 2012) For BMW R 1200 GS Adv. (- 2007) For BMW R 1200 GS Adv. (2008 - 2009) For BMW R 1200 GS Adv. (2010 - 2013) For BMW R 1300 GS For BMW F 650 GS (2008-) For BMW F 700 GS (-2016) For BMW F 700 GS (2017-) For BMW F 750 GS (2018-) For BMW F 800 GS (-07/2012) For BMW F 800 GS (08/2012 - 2016) For BMW F 800 GS (2017-)
- For BMW F 800 GS Adventure (2013-) For BMW F 850 GS (2018-) For BMW F 850 GS Adv (2019-) For BMW F 900 R For BMW F 900 XR For BMW G 650 GS (-2010) For BMW G 650 GS (2011-) For BMW G 650 GS Sertao For BMW K 1600 B For BMW K 1600 Grand America For BMW K 1600 GT (-2016) For BMW K 1600 GT (2017-) For BMW K 1600 GTL (-2016) For BMW K 1600 GTL (2017-) For BMW R 1200 GS LC (2013 - 2016) For BMW R 1200 GS LC (2017-) For BMW R 1200 GS LC Adv. (2014-) For BMW R 1200 RT ( - 2009) For BMW
- For BMW R 1200 RT LC (2014-) For BMW R 1250 GS* For BMW R 1250 GS Adventure For BMW R 1250 RT ( - 2020) For BMW R 1250 RT (2021 - ) For BMW R nineT (2014 - 2016) For BMW R nineT (2017-) For BMW S 1000 XR (-2019) For BMW S 1000 XR (2020-) For BMW G310GS For BMW R 1150 GS Adventure
- Condition: Aftermarket 100% Brand New Material: Teflon-coated CORDURA weave material Package:1 Pair side bags for panniers & 1 Tail bag for top box
- Special -strip with Velcro for secure attachment to the case Expands/compacts with perimeter zipper,Expandable up to 20 liter maximum capacity Crossed shock cords on top for quickly securing gloves, hat, etc as well as For Hepco & Becker top cases, with an easy to manage quick connection system. (Please check whether the size of the product is suitable before placing an order!!)
Last update on 2024-04-26 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
© 2023 BMW of North America, LLC. The contents of this document are confidential and should not be shared with third parties for distribution.
TEC632 VARIO SIDE CASES
RECALL 24E-029 HAS BEEN ISSUED FOR VARIO SIDE CASES FOR THE
R 1300 GS
OVERVIEW
•BMW has announced a delivery stop on Vario Side Cases for the R 1300 GS.
•No Vario Side Cases for the R 1300 GS should be installed on the motorcycle.
•Any customer sold unit should not be installed/used until the remedy is available. Please reach out to thosecustomers as needed.UPDATE: RETURN SHIPPING REMOVED We are currently evaluating whether the Vario Side Case repair can be performed at the dealer level based on new information. During this evaluation period, we kindly request that you refrain from shipping any cases back to the RDC’s.
NHTSA STATEMENT
Please be reminded that it is a violation of federal law (The Safety Act) for you to sell, lease or deliver any new motorcycle covered by this notification until the recall repair has been performed. This means that dealers may not legally deliver new motorcycles to consumers until they are fixed or use/sell replacement equipment/parts subject to this recall. Note also that substantial civil penalties apply to violations of the Safety Act. Also, you should not sell, lease or deliver any used motorcycles subject to a safety recall until the repair is completed. Please follow any special instructions that we provide to you for the return or disposition of recall parts. Bulletin #: AS-20-24A ☐Take Note☒Take Action
☐Retail Operator
☐Sales Pre-Owned
☒Business Manager
☒Parts & Accessories
☒General Manager
☐Sales New Bike
☒Service
☐Administration
Name:
Phone Number:
Title: Email:
Source: Parts Logistics Date: 03/21/2024 Supersedes: – AS-20-24
© 2023 BMW of North America, LLC. The contents of this document are confidential and should not be shared with third parties for distribution.
Description Part Number
Vario case, left
77 41 9 444 361
Vario case, right
77 41 9 444 362
Vario case, left
77 41 4 B0C 3D9
Vario case, right
77 41 4 B0C 3E0
Vario case, left
77 41 4 B0C 3E1
Vario case, right
77 41 4 B0C 3E2
MORE DETAILS
•TEC632 is valid from March 18, 2024, through April 30, 2024. The deadline for filing a claim under TEC632 is April30, 2024.
MORE QUESTIONS?
Aftersales Business Development Manager
Material Planning and Parts Logistics Analyst
**************************************************************************************************************
AS2024 – TEC632 Vario Side Cases
UPDATE: RECALL 24E-029 HAS BEEN ISSUED FOR THE VARIO SIDE CASE FOR R 1300 GS
Overview
• BMW has announced a delivery stop on Vario Side Cases for the R 1300 GS.
• No Vario Side Cases for the R 1300 GS should be installed on the motorcycle.
• Any customer sold unit should not be installed/used until the remedy is available. Please reach out to those customers as needed.
Update: Return Shipping Removed
We are currently evaluating whether the Vario Side Case repair can be performed at the dealer level based on new information. During this evaluation period, we kindly request that you refrain from shipping any cases back to the RDC’s.
Mar 21, 2024,
**************************************************************************************************************
OMB Control No.: 2127-0004
Part 573 Safety Recall Report 24E-029
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
BMW of North America, LLC MAR 21, 2024 NHTSA Recall No. : 24E-029 Manufacturer Recall No. : NR Manufacturer Information :
Manufacturer Name : BMW of North America, LLC Address : P.O. Box 1227
Westwood NJ 07675-1227
Company phone : 18005257417
Population :
Number of potentially involved : 1,600 Estimated percentage with defect : 100 %
Equipment Information : Brand / Trade 1 :
Model : BMW
BMW Motorcycle Dealer Accessory Side Cases for R 1300 GS Part No. : 77 41 9 444 361/362 Size : NR Function : NR
Descriptive Information : Approximately 1,600 dealer accessory side cases (800 sets left/right) may not have been produced by the supplier according to specifications.
Basis for recall population determination: Accessory sales records and parts logistics information were reviewed to determine the number of potentially affected side cases that may have been delivered to dealers or retailed to customers. Recall component difference to non-recall component: The dealer accessory side cases may not have been produced by the supplier according to specifications. Production Dates : JUN 29, 2023 – NOV 23, 2023
Description of Defect :
Description of the Defect : This safety recall involves the dealer accessory side cases. The lid of the side case may appear to be securely closed by the user. However, in isolated cases, both latch hooks may not have snapped properly into the lock. If this occurred, the side case would not be securely closed and could open during riding.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : If the side case lid opened while riding, the contents of the side case could fall
out. Also, the hinges and holding strap may not securely hold the lid and Part 573 Safety Recall Report 24E-029 Page 2 could break, causing the lid to become detached from the side case. The case contents and/or the lid could become a hazard for road users and increase the risk of a crash.
Description of the Cause : NR Identification of Any Warning NR
that can Occur : Involved Components : Component Name : Dealer Accessory Vario Side Cases for R 1300 GS Component Description : Dealer Accessory Vario Side Cases for R 1300 GS Component Part Number : 77419444361, 77419444362 Supplier Identification : Component Manufacturer
Name : TOURATECH GmbH
Address : Auf dem Zimmermann 7-9 Niedereschach Foreign States 78078
Country : Germany Chronology :
On October 31,2023, during a dealer demonstration ride of a BMW R 1300 GS in a non-US market, a side case lid opened, the hinges and holding strap broke and the lid contacted the roadway. An engineering investigation was initiated, the part was returned for analysis, and the supplier was contacted. Tests and analyses were planned to focus on the design of the locking mechanism and the hinges to understand the precision of the locking feature, and the mechanical resistance for the latch hooks when pushed for closing. The supplier reviewed its records and confirmed that all side cases since start of production had been tested in a 100% end-of-line test, which ensured that all cases would be capable of secure latching if operated correctly. Additional customer complaints were received in non-US markets, in which customers complained that their side case lids had opened and, in most cases, became detached and contacted the roadway. These parts were requested to be returned for analysis. The first field part was received for analysis on December 1, 2023. Between December 2023 and March 2024, tests and analyses found that improper locking of the latch hooks The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 24E-029 Page 3 was facilitated by the geometry of the latch hooks and the position of the hinges. Additional analyses confirmed that for a lid to detach, both latch hooks would need to be improperly secured. The tests indicated that even if only one of two latch hooks (upper left- or right-hand corner of the side case) was properly locked, the lid would not open even under severe riding stress. Therefore, side cases opening during riding had to be improperly latched on both corners. On March 14, 2024, BMW decided to conduct a voluntary safety recall for the accessory side cases. Between November 2023 and March 2024, approximately 14 customer complaints were received in non-US markets. BMW has not received any reports, nor is BMW otherwise aware, of any accidents or injuries that relate to this issue. Description of Remedy :
Description of Remedy Program : The locking mechanism and hinges of the side cases will be reworked to
ensure that they are functioning correctly. Although owner notification is not required – because the last known purchasers to BMW of the accessory side cases are the motorcycle dealers
– nevertheless, BMW plans to notify R 1300 GS owners who have purchased a motorcycle as of the date of this report. These owners will be notified by First Class mail and instructed to take their accessory side cases to an authorized BMW motorcycle dealer to have the remedy performed for free. How Remedy Component Differs from Recalled Component : Dealer Accessory Vario Side Cases for R 1300 GS – part number – 77 41 9 444 361 (left) / 77 41 9 444 362 (right) Identify How/When Recall Condition NR was Corrected in Production : Recall Schedule :
Description of Recall Schedule : Dealer notification is planned to begin and end on March 29, 2024.
Owner notification is planned to begin and end on May 13, 2024. Planned Dealer Notification Date : MAR 29, 2024 – MAR 29, 2024
Planned Owner Notification Date : MAY 13, 2024 – MAY 13, 2024 The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 24E-029
Page 4
The information contained in this report was submitted pursuant to 49 CFR §573
Purchaser Information :
The following manufacturers purchased this defective/noncompliant equipment for possible use or installation in new motor vehicles or new items of motor vehicle equipment:
Name : NR Address : NR
NR Country : NR Company Phone : NR
* NR – Not Reported
**************************************************************************************************************
4/2/24, 12:41 PM 00 02 24_INFO – Vario Case/s Compensation
about:blank 1/4
SIB 00 02 24
INFO – Vario Case/s Compensation
2024-04-01
MODEL
Model Model Description Model Code
KA1 R 1300 GS 0M23
SITUATION
1. Description of defect or noncompliance:
a. This safety recall involves the dealer accessory top case. The locking flap of the top case
(fastening the top case to the luggage carrier of the motorcycle) may appear to be securely
closed by the user. However, in this condition, the key can be removed. If this occurred, the top
case would not be securely fastened to the motorcycle.
2. Description of safety risk:
a. If the top case detached from the motorcycle, it could become a hazard for road users, and
increase the risk of a crash.
Vario Side Cases – Recall 24E-029:
1. Description of defect or noncompliance:
a. This safety recall involves the dealer accessory side cases. The lid of the side case may appear
to be securely closed by the user; however, in isolated cases, both latch hooks may not have
snapped properly into the lock. If this occurred, the side case would not be securely closed and
could open during riding.
2. Description of safety risk:
a. If the side case lid opened while riding, the contents of the side case could fall out. Also, the
hinges and holding strap may not securely hold the lid and could break, causing the lid to
become detached from the side case. The case contents and/or the lid could become a hazard
for road users and increase the risk of a crash.
PROCEDURE
In principle, there must be an order for one or more parts of the Vario luggage system and a customer
complaint.
Recommended Utilization
This compensation should be an active response to a negative customer experience e.g., customer
expressly complains about the delayed delivery or repair of the accessories (and this could possibly
jeopardize the delivery/retail report of the vehicle as a result).
Copyright ©2024 MOTORRAD USA, a division of BMW of North America, LLC. All Rights Reserved
———
4/2/24, 12:41 PM 00 02 24_INFO – Vario Case/s Compensation
about:blank 2/4
Compensation can be used towards a future purchase of the Vario Case/s. Alternatively items such as soft
bags are primarily suitable substitutes.
PARTS INFORMATION
Recommendations:
Part Number Description Image
71607689674 Vehicle cover A
77455A0E751 Tank bag Black Collection large B
77455A5CE48 Connection tank bag (needed for tank bags) n/a
77455A3C3D7 Tank bag Urban Collection large C
77455A0E752 Tank bag Black Collection small D
77455A3C3D9 Tank bag Urban Collection small E
77455A50328 Tank bag Adventure Collection large F
77455A503A6 Tank bag Adventure Collection small G
77495A0E757 Rear bag Black Collection large H
77495A0E758 Rear bag Black Collection small I
77495A3C3D0 Rear bag Urban Collection large J
77495A3C3E0 Rear bag Urban Collection small K
77495A503B9 Rear bag Adventure Collection large L
77495A50044 Rucksack Urban Collection M
77495A503C1 Rucksack Adventure Collection N
CLAIM INFORMATION
As luggage systems are accessories, the compensation must be claimed using Type 2 parts warranty.
The warranty claim must be created using the Chassis number of the associated R 1300 GS.
Claims can only be submitted if there are no repair solutions and or parts releases for the Vario luggage
system.
The comment field of the warranty claim must be clearly documented as follows:
1. Why the compensation was offered.
2. What was offered as part of the program.
Defect code
90 00 06 12 00 Availability of parts
Reference Images
A B
C D E F
Copyright ©2024 MOTORRAD USA, a division of BMW of North America, LLC. All Rights Reserved
4/2/24, 12:41 PM 00 02 24_INFO – Vario Case/s Compensation
about:blank 3/4
G H I J
K L M N
QUESTIONS REGARDING THIS BULLETIN
Technical inquiries Contact the BMW Technical Support Group via TSARA
Warranty inquiries Submit an IDS ticket to the Warranty Department
Parts inquiries Submit an IDS ticket to the Motorrad Parts Department
Copyright ©2024 MOTORRAD USA, a division of BMW of North America, LLC. All Rights Reserved
4/2/24, 12:41 PM 00 02 24_INFO – Vario Case/s Compensation
about:blank 4/4
Copyright ©2024 MOTORRAD USA, a division of BMW of North America, LLC. All Rights Reserved
**************************************************************************************************************
OMB Control No.: 2127-0004
Part 573 Safety Recall Report 24E-029
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
BMW of North America, LLC MAR 26, 2024 NHTSA Recall No. : 24E-029 Manufacturer Recall No. : NR Manufacturer Information :
Manufacturer Name : BMW of North America, LLC Address : P.O. Box 1227
Westwood NJ 07675-1227
Company phone : 18005257417
Population :
Number of potentially involved : 1,600 Estimated percentage with defect : 100 %
Equipment Information : Brand / Trade 1 :
Model : BMW
BMW Motorcycle Dealer Accessory Side Cases for R 1300 GS Part No. : 77 41 9 444 361/362 Size : NR Function : NR
Descriptive Information : Approximately 1,600 dealer accessory side cases (800 sets left/right) may not have been produced by the supplier according to specifications.
Basis for recall population determination: Accessory sales records and parts logistics information were reviewed to determine the number of potentially affected side cases that may have been delivered to dealers or retailed to customers. Recall component difference to non-recall component: The dealer accessory side cases may not have been produced by the supplier according to specifications. Production Dates : JUN 29, 2023 – NOV 23, 2023
Description of Defect :
Description of the Defect : This safety recall involves the dealer accessory side cases. The lid of the side case may appear to be securely closed by the user. However, in isolated cases, both latch hooks may not have snapped properly into the lock. If this occurred, the side case would not be securely closed and could open during riding.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : If the side case lid opened while riding, the contents of the side case could fall
out. Also, the hinges and holding strap may not securely hold the lid and Part 573 Safety Recall Report 24E-029 Page 2 could break, causing the lid to become detached from the side case. The case contents and/or the lid could become a hazard for road users and increase the risk of a crash.
Description of the Cause : NR Identification of Any Warning NR
that can Occur : Involved Components : Component Name : Dealer Accessory Vario Side Cases for R 1300 GS Component Description : Dealer Accessory Vario Side Cases for R 1300 GS Component Part Number : 77419444361, 77419444362 Supplier Identification : Component Manufacturer
Name : TOURATECH GmbH
Address : Auf dem Zimmermann 7-9 Niedereschach Foreign States 78078
Country : Germany Chronology :
On October 31,2023, during a dealer demonstration ride of a BMW R 1300 GS in a non-US market, a side case lid opened, the hinges and holding strap broke and the lid contacted the roadway. An engineering investigation was initiated, the part was returned for analysis, and the supplier was contacted. Tests and analyses were planned to focus on the design of the locking mechanism and the hinges to understand the precision of the locking feature, and the mechanical resistance for the latch hooks when pushed for closing. The supplier reviewed its records and confirmed that all side cases since start of production had been tested in a 100% end-of-line test, which ensured that all cases would be capable of secure latching if operated correctly. Additional customer complaints were received in non-US markets, in which customers complained that their side case lids had opened and, in most cases, became detached and contacted the roadway. These parts were requested to be returned for analysis. The first field part was received for analysis on December 1, 2023. Between December 2023 and March 2024, tests and analyses found that improper locking of the latch hooks The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 24E-029 Page 3 was facilitated by the geometry of the latch hooks and the position of the hinges. Additional analyses confirmed that for a lid to detach, both latch hooks would need to be improperly secured. The tests indicated that even if only one of two latch hooks (upper left- or right-hand corner of the side case) was properly locked, the lid would not open even under severe riding stress. Therefore, side cases opening during riding had to be improperly latched on both corners. On March 14, 2024, BMW decided to conduct a voluntary safety recall for the accessory side cases. Between November 2023 and March 2024, approximately 14 customer complaints were received in non-US markets. BMW has not received any reports, nor is BMW otherwise aware, of any accidents or injuries that relate to this issue. Description of Remedy :
Description of Remedy Program : The locking mechanism and hinges of the side cases will be reworked to
ensure that they are functioning correctly. Although owner notification is not required – because the last known purchasers to BMW of the accessory side cases are the motorcycle dealers
– nevertheless, BMW plans to notify R 1300 GS owners who have purchased a motorcycle as of the date of this report. These owners will be notified by First Class mail and instructed to take their accessory side cases to an authorized BMW motorcycle dealer to have the remedy performed for free. If this condition were to occur to a potentially affected accessory side case prior to this recall, the remedy would be covered by the BMW New Parts and Accessories Limited Warranty program.
Therefore, reimbursement for a pre-notification remedy re Part 573.13 and Part 577.11 is not necessary. How Remedy Component Differs from Recalled Component : Dealer Accessory Vario Side Cases for R 1300 GS – part number – 77 41 9 444 361 (left) / 77 41 9 444 362 (right) Identify How/When Recall Condition NR was Corrected in Production : Recall Schedule :
Description of Recall Schedule : Dealer notification is planned to begin and end on March 29, 2024.
Owner notification is planned to begin and end on May 13, 2024. Planned Dealer Notification Date : MAR 29, 2024 – MAR 29, 2024
Planned Owner Notification Date : MAY 13, 2024 – MAY 13, 2024 The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 24E-029
Page 4
The information contained in this report was submitted pursuant to 49 CFR §573
Purchaser Information :
The following manufacturers purchased this defective/noncompliant equipment for possible use or installation in new motor vehicles or new items of motor vehicle equipment:
Name : NR Address : NR
NR Country : NR Company Phone : NR
* NR – Not Reported
**************************************************************************************************************
OMB Control No.: 2127-0004
Part 573 Safety Recall Report 24E-029
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
BMW of North America, LLC MAR 26, 2024 NHTSA Recall No. : 24E-029 Manufacturer Recall No. : NR Manufacturer Information :
Manufacturer Name : BMW of North America, LLC Address : P.O. Box 1227
Westwood NJ 07675-1227
Company phone : 18005257417
Population :
Number of potentially involved : 1,600 Estimated percentage with defect : 100 %
Equipment Information : Brand / Trade 1 :
Model : BMW
BMW Motorcycle Dealer Accessory Side Cases for R 1300 GS Part No. : 77 41 9 444 361/362 Size : NR Function : NR
Descriptive Information : Approximately 1,600 dealer accessory side cases (800 sets left/right) may not have been produced by the supplier according to specifications.
Basis for recall population determination: Accessory sales records and parts logistics information were reviewed to determine the number of potentially affected side cases that may have been delivered to dealers or retailed to customers. Recall component difference to non-recall component: The dealer accessory side cases may not have been produced by the supplier according to specifications. Production Dates : JUN 29, 2023 – NOV 23, 2023
Description of Defect :
Description of the Defect : This safety recall involves the dealer accessory side cases. The lid of the side case may appear to be securely closed by the user. However, in isolated cases, both latch hooks may not have snapped properly into the lock. If this occurred, the side case would not be securely closed and could open during riding.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : If the side case lid opened while riding, the contents of the side case could fall
out. Also, the hinges and holding strap may not securely hold the lid and Part 573 Safety Recall Report 24E-029 Page 2 could break, causing the lid to become detached from the side case. The case contents and/or the lid could become a hazard for road users and increase the risk of a crash.
Description of the Cause : NR Identification of Any Warning NR
that can Occur : Involved Components : Component Name : Dealer Accessory Vario Side Cases for R 1300 GS Component Description : Dealer Accessory Vario Side Cases for R 1300 GS Component Part Number : 77419444361, 77419444362 Supplier Identification : Component Manufacturer
Name : TOURATECH GmbH
Address : Auf dem Zimmermann 7-9 Niedereschach Foreign States 78078
Country : Germany Chronology :
On October 31,2023, during a dealer demonstration ride of a BMW R 1300 GS in a non-US market, a side case lid opened, the hinges and holding strap broke and the lid contacted the roadway. An engineering investigation was initiated, the part was returned for analysis, and the supplier was contacted. Tests and analyses were planned to focus on the design of the locking mechanism and the hinges to understand the precision of the locking feature, and the mechanical resistance for the latch hooks when pushed for closing. The supplier reviewed its records and confirmed that all side cases since start of production had been tested in a 100% end-of-line test, which ensured that all cases would be capable of secure latching if operated correctly. Additional customer complaints were received in non-US markets, in which customers complained that their side case lids had opened and, in most cases, became detached and contacted the roadway. These parts were requested to be returned for analysis. The first field part was received for analysis on December 1, 2023. Between December 2023 and March 2024, tests and analyses found that improper locking of the latch hooks The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 24E-029 Page 3 was facilitated by the geometry of the latch hooks and the position of the hinges. Additional analyses confirmed that for a lid to detach, both latch hooks would need to be improperly secured. The tests indicated that even if only one of two latch hooks (upper left- or right-hand corner of the side case) was properly locked, the lid would not open even under severe riding stress. Therefore, side cases opening during riding had to be improperly latched on both corners. On March 14, 2024, BMW decided to conduct a voluntary safety recall for the accessory side cases. Between November 2023 and March 2024, approximately 14 customer complaints were received in non-US markets. BMW has not received any reports, nor is BMW otherwise aware, of any accidents or injuries that relate to this issue. Description of Remedy :
Description of Remedy Program : The locking mechanism and hinges of the side cases will be reworked to
ensure that they are functioning correctly. Although owner notification is not required – because the last known purchasers to BMW of the accessory side cases are the motorcycle dealers
– nevertheless, BMW plans to notify R 1300 GS owners who have purchased a motorcycle as of the date of this report. These owners will be notified by First Class mail and instructed to take their accessory side cases to an authorized BMW motorcycle dealer to have the remedy performed for free. If this condition were to occur to a potentially affected accessory side case prior to this recall, the remedy would be covered by the BMW New Parts and Accessories Limited Warranty program.
Therefore, reimbursement for a pre-notification remedy re Part 573.13 and Part 577.11 is not necessary. How Remedy Component Differs from Recalled Component : Dealer Accessory Vario Side Cases for R 1300 GS – part number – 77 41 9 444 361 (left) / 77 41 9 444 362 (right) Identify How/When Recall Condition NR was Corrected in Production : Recall Schedule :
Description of Recall Schedule : Dealer notification is planned to begin and end on March 29, 2024.
Owner notification is planned to begin and end on May 13, 2024. Planned Dealer Notification Date : MAR 29, 2024 – MAR 29, 2024
Planned Owner Notification Date : MAY 13, 2024 – MAY 13, 2024 The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 24E-029
Page 4
The information contained in this report was submitted pursuant to 49 CFR §573
Purchaser Information :
The following manufacturers purchased this defective/noncompliant equipment for possible use or installation in new motor vehicles or new items of motor vehicle equipment:
Name : NR Address : NR
NR Country : NR Company Phone : NR
* NR – Not Reported
**************************************************************************************************************
**************************************************************************************************************
**************************************************************************************************************
SEOCONTENT-END
