September 28, 2022 NHTSA CAMPAIGN NUMBER: 22V721000
Headlights Missing Metallic Coating/FMVSS 108
Improperly illuminated road signs may be difficult for the driver to read, increasing the risk of a crash.
NHTSA Campaign Number: 22V721
Manufacturer BMW of North America, LLC
Components EXTERIOR LIGHTING
Potential Number of Units Affected 2
Summary
BMW of North America, LLC (BMW) is recalling certain 2023 Rolls-Royce Phantom vehicles. The headlights may not have received a metal coating application, which can result in the low beams not adequately illuminating road signs. As such, these vehicles fail to comply with the requirements of Federal Motor Vehicle Safety Standard number 108, “Lamps, Reflective Devices, and Associated Devices.”
Remedy
Dealers will replace the headlights, free of charge. The affected vehicles are still at dealerships and therefore no owner notification letters will be mailed. Owners may contact Rolls-Royce customer service at 1-877-877-3735.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.
Check if your Rolls-Royce has a Recall
00 63 82 01 00 – Recall RR11 Headlight Replacement
USA – TECHNICAL CAMPAIGN (Non-Compliance Recall 22V-721) – Complete before vehicle handover
PLEASE DO NOT SELL, LEASE OR DELIVER ANY VEHICLE COVERED BY THIS NOTIFICATION UNTIL THE DELIVERY STOP REPAIR HAS BEEN PERFORMED. THIS MEANS THAT DEALERS MAY NOT DELIVER NEW MOTOR VEHICLES TO A CONSUMER UNTIL IT IS FIXED OR USE/SELL REPLACEMENT EQUIPMENT /PARTS SUBJECT TO A DELIVERY STOP.
ALSO, YOU SHOULD NOT SELL, LEASE OR DELIVER ANY PROVENANCE (CPO) OR USED VEHICLES SUBJECT TO A DELIVERY STOP UNTIL THE REPAIR IS COMPLETED.
1. Situation
A small number of Rolls-Royce Phantom (RRll) vehicles have been identified as having an issue with the front headlights. Due to a supplier production error, a specific part of the headlight combination unit did not receive a metal coating during manufacturing process. As a result, the upper road sign illumination aspect of the low beam does not fully meet legislation requirements in certain markets.
Vehicles identified within this campaign will need front headlights replaced.
Dealers should check for vehicles which are subject to this Technical Campaign using ISPA (Integrated Service Processes Application) or S-Gate/ AlR.
2. Affected vehicles
This Recall Campaign involves the following RRll Rolls-Royce Phantom vehicles produced between July 12, 2022, and July 14, 2022.
3. Procedure
Replace both front headlights as per ISTA/AlR repair instructions below:
63 12 021 – Remove and install both headlights.
6312 616 – Replacing both LED headlights (LED headlight laser) (headlight removed).
Please note the following additional points when removing the Illuminated grill:
- Prior to removing the grill, the air guide fixings need to be removed.
- Disconnect plug connectors for grill illumination
3. Parts Information
Description | Part Number | Quantity |
Headlight left | 6311 5 A1D 8C3 | 1 |
Headlight right | 6311 5 A1D 8C4 | 1 |
Chronology :
On September 6, 2022, the supplier informed Rolls-Royce of a potential issue involving certain headlamps.
Initial information suggested that a supplier production process issue may have occurred which could affect certain aspects of headlamp illumination. An engineering review was initiated.
Reviews of supplier documentation and test results were conducted. A review of headlamp regulatory requirements including FMVSS 108 was performed. Preliminary information suggested that a possible noncompliance might exist. Further reviews and assessments were conducted.
Vehicle assembly information and supplier production records were reviewed to determine the number and production dates of potentially affected vehicles.
On September 21, 2022, Rolls-Royce decided to conduct a voluntary non-compliance recall.
Rolls-Royce has not received any reports, nor is Rolls-Royce otherwise aware, of any accidents or injuries that may be related to this issue.
1 Affected Product
Vehicle
MAKE | MODEL | YEAR |
ROLLS-ROYCE | PHANTOM | 2023 |
5 Associated Documents
Recall Acknowledgement
RCAK-22V721-6355.pdf 645.096KB
RCAK-22V721-6355
Noncompliance Notice 573 Report
RCLRPT-22V721-6662.PDF 214.08KB
RCLRPT-22V721-6662
Remedy Instructions and TSB
RCRIT-22V721-2562.pdf 916.82KB
RCRIT-22V721-2562
Manufacturer Notices(to Dealers,etc) – 00 63 82 01 00 – RECALL RR11 HEADLIGHT REPLACEMENT (USA)
RCMN-22V721-8301.pdf 105.171KB
RCMN-22V721-8301
Recall Quarterly Report #1, 2022-4
RCLQRT-22V721-2211.PDF 211.128KB
RCLQRT-22V721-2211
